Reciprocal Frame Structures

Channel:

Rhino Grasshopper

Subscribers:

91,600

Published on October 11, 2022 7:44:41 AM ● Video Link: https://www.youtube.com/watch?v=udc4yFChgwE

Duration: 6:17

5,886 views

154

Reciprocal frame structures are a family of structures that are increasingly attracting interest from many participants in the construction industry.

They offer architectural opportunities through their expressive form and structural advantages due to their specific configuration.

A possible definition of a reciprocal frame is a grid of linear members where each member simultaneously supports and is supported by its neighboring members.

Therefore, the members are structurally interdependent and in a structural hierarchy of equal importance.

Although the basic RF configurations are typically used to enclose a regular rectangular/polygonal plan form, current built cases have also presented reciprocal frames with irregular shapes.

Up-to-date digital design tools enable a broad spectrum of opportunities for RFs, facilitating the design and fabrication of complex RF geometries and building typologies for diverse purposes.

Text Source: Reciprocal Frame Structures / structuremag
